EME introduces the PicoPetite - a compact, self contained, full featured Data Acquisition System

The EME PicoPetite is the most compact, self contained, full featured Data Acquisition System (DAS) ever designed and manufactured. This DAS measures only 2.00 inches (length) by 2.33 inches (width) by 1.1 inches (height) and weighs less than 5 ounces for 32 channels. Additional channels can be added or removed in 8 channel increments adding or subtracting only 0.218 inches per 8 Channels to the height dimension.

Up to 64 channels can be installed in a single unit and units can be daisy chained together for extremely high channel counts. EME has sacrificed no features to achieve this small size. The PicoPetite uses many of the deign features of the highly successful EME PicoDAS.

Features:

• Configurations of 8, 16, 24, 32, 40, 48, 56, and 64 analogue channels available
• Airborne (tm) Miniature DSub Connectors
• Synchronous triggering and simultaneous sampling between daisy chained units
• Simultaneous Sampling of 1 Hz to 250 kHz
• Individual 16-bit A/D converters for each channel
• Gain range of 1 to 10000
• Analogue Input of +/- 5 volts
• ICP Module allows any Analogue Input to accept ICP Sensors (28 Volt @ 3.6 ma with Adjustable High Pass Filter (Optional))
• Offsetting available for the full scale at the Input or at the Output
• .1% calibrated accuracy
• Internal shunt calibration
• Internal 1/2 pseudo bridge completion resistors for all channels (user selectable)
• Simultaneous sampling of channels
• Individual fold-back current limited excitation sources of 0, 2.5v, 5.0v, and 10.0v for each analogue input. Current limit can be customer set or delivered as 100ma standard.
• 6 pole Digital filtering with variable cut-off frequencies
• 5 pole Fixed Butterworth filter @ 25kHz (Other frequencies available)
• Meets SAE J211 specifications
• Sensor identification using DALLAS ID's (Optional with 51-pin Connectors)
• Automatic calibration of analogue channels
• Multi-stage sampling offering the sample rate to change up to 3 times at a set time or on the fly with an event line
• Start/Stop Data Recording using an event line
• Segmented Data Collection Mode offers the ability to collect multiple acquisitions under one arming.
• Gain Measurement and Excitation Measurement while sensors are connected
• Battery input measurement and current monitor recording during acquisition
• 8 GB, 16 GB, 32 GB, 64 GB, 128 GB or 256 GB of non-volatile memory
• 4 digital output channels
• 8 digital event input channels (Plus 4 Events per 8-channel Analogue Module)
• PCM Irig-B Input as well as PCM 106-01 Telemetry Output (Optional)
• Internal GPS Module (Optional)
• 10-16.5 volt power input range
• Internal Digital NiCAD/NiMH Peak Charger with automatic switching (Optional)
• Low power consumption .250 amps for 32 channels at 12 volts in full analogue mode
• Serial communication using Ethernet 100baseT
• Durability of Shock:

  +/-250g, 12 msec 1/2 sine wave pulse
  +/-70g, 500 msec 1/2 sine wave,
  +/-35g, 2 sec 1/2 sine wave,
  +/-60g 100 msec duration, on all axis

• Windows XP/Vista/7/8 32-bit or 64-bit (tm) Control/Processing Software
• EMI/RFI Shielding
• 1 year warranty
• The latest in technology

For further information on the EME Pico Petite in Australia or New Zealand, please contact Metromatics on +61 7 3868 4255 or sales@metromatics.com.au

For outside this area, please contact EME Corp +1 410 544 8563 or info@emecorp.com

Metromatics are now the exclusive Australasian Distributors for the X-ES Product Range



Commercial off the Shelf (COTS) and Ruggedised Embedded Computing Boards and Systems Market Leader, Extreme Engineering Solutions (X-ES ), announces the appointment of Metromatics as their exclusive Australian and New Zealand distributor for their product range.  With a twenty five-year history of providing embedded computing and system solutions sales, distribution and support, and offices in Brisbane, Sydney, Melbourne, Adelaide and Auckland, Metromatics is the perfect partner to distribute X-ES’s Embedded Board and Systems range across Australasia.



Metromatics has an extensive industry-specific history, currently representing companies who specialise in manufacturing Rugged Peripherals, UPS Power Systems, Data Acquisition Systems and Automatic Test Equipment.  The addition of X-ES’s Embedded Computing Solutions will provide Metromatics’ customers and the Australasian Commercial, Industrial, Communications and Defence Market as a whole, access and support to a comprehensive range of commercial grade to fully ruggedised boards and systems utilising the latest processor technology.  X-ES also excel in providing custom products, from modified COTS to full scale custom designs and will be able to provide Australasian Customers embedded technological solutions quicker.



Metromatics’ appointment creates the opportunity to couple excellent service with locality, offering real-time response to customer demand.  X-ES will continue to provide infrastructure support to Metromatics in terms of sales and technical assistance from X-ES’s experienced sales, technical and engineering team.

For further information or pricing on X-ES's excellent products in Australia & New Zealand, please contact Metromatics +61 7 3868 4255 or sales@metromatics.com.au
For outside the above mentioned area, please contact X-ES directly on +1 608 833 1155 or sales@xes-inc.com
